16KW 20KVA German Diesel Generator with Soundproof

16KW 20KVA German Diesel Generator with Soundproof

MODEL NUMBER: DC17W-50P

SPEED: 1500/1800 RPM

FREQUENCY: 50/60HZ

RATED POWER: 20KVA/16KW

RATED VOLTAGE: 400/230V ADJUSTABLE

Project Reference:Diesel Generator Set Project Refernce

ABOUT WAGNA ENGINE

Wagna D-series engine, reliability and applicability has been improved according to the user's power demand through years' power supply experience, can fully meet the needs for the prime power generation, backup power supply, continuous power generation.

Wagna D-series engine, according to the user's demand , improve the reliability and applicability of power generation applications, can fully meet the needs of prime power generation, backup power supply ,continuous power generation for reliable operation.

APPLICATION

WAGNA GENERATOR SETS CAN BE APPLIED INTO VARIOUS FIELDS .

Farmings – Mining – Construction – Airport – Hotels – Date Centre – Oilfield – Malls – Community

Shopping Mall – Municipal Administration – Environmental Construction

Standard configuration

• Wagna Engine

• Installation kit

• Wagna Alternator

• 40℃ water-cooled radiator

• Industrial silencer/pipe

• Steel painted base frame

• anti-vibration pad

• Delixi/ABB breaker

• WE8010 intelligent control panel

• Maintenance-free battery/Charger/Cable

WAGNA CONTROLLER

Control System

WE8010 is the remote monitoring module of the generator set controller.With RS485 port it can realize functions of remote start/stop, data measuring, and alarm display etc. it is applicable for single remote monitoring system. It can be in the monitoring mode, realizing only monitoring, not controlling, or it can be changed over to remote control mode by local module transfer,monitored and controlled remotely.

WE8010 remote monitoring module uses micro-processing technique and 132 x64 LCD display. It can be widely used in all types of automatic control system with compact structure, simple connections and high reliability.

1. 132x64 LCD display with backlight, 8 language interface (Simplified Chinese, English, Spanish, Russian, Portuguese, Turkish, Polish and French), push-button operation;

2. Acrylic hard screen, better wear proof and scratch resistance property;

3. Silica-gel panel and keys with strong adaptability in higher and lower temperature environments;

4. RS485 communication port which can achieve "three-remote" (remote, control, remote, measur

ement and remote communication) functions via MODBUS protocol;

5. Wide power supply range:(8~35)V DC, accom modating to different starting battery volts;

6. All parameters use digital modulation, getting rid of analog modulation of conventional potentiometer, improving wholesome reliability and stability;

7. Controller is fixed by fixing metal clips;

                                                   Regarding the commonly standby and prime definitions of product technical parameters

Prime Rating

Applicable for supplying power to a varying load in lieu of utility for an unlimited amount of running time. A 10% overload capacity is available for 1 out of every 12 hours. The Prime Power option is only available on International applications. Power ratings in accordance with ISO 8528-1, Second Edition.

Standby Rating

Applicable for a varying emergency load for the duration of a utility power outage with no overload capability.

Standard Reference Conditions

Note: Standard reference conditions 25°C (77°F) air inlet temp, 100m (328ft) A.S.L. 30% relative humidity.

Fuel consumption data at full load with diesel fuel with specific gravity of 0.85 and conforming to BS2869: 1998, Class A2.

WANGA with Certification of • ISO 9001

• EN 60204-1

• EN ISO 12100

• EN ISO 8528-13

• EN ISO 3046-1-2002
